Camera Image Sensor 1/2.8″ CMOS Max. Resolution 2304 (H) × 1296 (V) Electronic Shutter Speed 1 s–1/100,000 s Min. Illumination 0.0005 lux@F1.0 (Color, 30 IRE);
0 lux (Illuminator on)Illumination Distance 30 m (98.43 ft) (Warm light) Illuminator Number 4 (Warm light) Lens Focal Length 3.6 mm Max. Aperture F1.0 Field of View H: 81.6°; V: 44.3°; D: 96.4° PTZ Pan/Tilt Range Pan: 0° to 345°; Tilt: 0° to 90° Smart Event Human Detection Yes Vehicle Detection Yes Video Video Compression Smart H.265+; H.265; Smart H.264+; H.264B; H.264M; H.264H; MJPEG(Sub Stream 1) Video Frame Rate Main stream: 3M/1080p/720p@(1–15 fps)
Sub stream 1: 640 × 360/QVGA@(1–15 fps)Day/Night Color/B/W WDR 120 dB Motion Detection Yes Image Rotation 180° Audio Audio Compression PCM, G.711A, G.711Mu Built-in MIC Yes Built-in Speaker Yes Network Network Port RJ-45 (10/100 Base-T) Wi-Fi Standard IEEE802.11b; IEEE802.11g; IEEE802.11n; IEEE802.11ax Wi-Fi Frequency Range 2.4 GHz Wi-Fi Transmission Rate 229 Mbps Wi-Fi Pairing Bluetooth pairing Max. Transmission Power ≤20 dBm@2400–2483.5 MHz Interoperability ONVIF (Profile S & Profile G & Profile T); CGI; SDK Storage Micro SD card (Up to 512 GB); FTP Management Software DMSS; NVR Mobile Client iOS; Android Function Abnormal Sound Alarm Yes Certification Certifications CE Power Power Supply 12 VDC, 1 A ± 10% Power Consumption Basic: 3 W
Max. (Basic power consumption + WDR + Light on + PTZ operation): 9 WEnvironment Operating Temperature –30 °C to +55 °C (–22 °F to +131 °F) Operating Humidity ≤95% Protection IP66; TVS 2000 V lightning proof; surge protection; voltage transient protection Structure Product Dimensions 153.5 mm × Φ129.3 mm (6.04″ × Φ5.09″) Net Weight 0.60 kg (1.32 lb)
