    5MP Smart Dual Light HDCVI Fixed-focal Bullet Camera

    Valoraciones
    HFW1500RLP-IL-ADisponibles: 498

    > Max. 25 fps@5MP (16:9 video output)

    > Starlight, 3D NR

    > Smart Dual Light.

    > 30 m illumination distance.

    > Built-in Mic.

    > 3.6 mm fixed lens (2.8 mm optional).

    > CVI/CVBS/AHD/TVI switchable.

    IP67, 12 VDC.

    Camera
    Image Sensor 5 MP CMOS
    Max. Resolution 2880 (H) × 1620 (V)
    Scanning System Progressive
    Electronic Shutter Speed PAL: 1/25 s–1/100,000 s
    NTSC: 1/30 s–1/100,000 s
    Min. Illumination 0.01 lux@F1.6 (Color, 30 IRE)
    0.001 lux@F1.6 (B/W, 30 IRE)
    0 lux (Illuminator on)
    S/N Ratio >65 dB
    Illumination Distance IR: 30 m (98.43 ft)
    Warm Light: 30 m (98.43 ft)
    Illuminator On/Off Control Auto
    Illuminator Number 2 (Multi-core light)
    Angle Adjustment Pan: 0°–360°
    Tilt: 0°–90°
    Rotation: 0°–360°
    Lens
    Lens Type Fixed-focal
    Auto Focus No
    Lens Mount M12
    Focal Length 2.8 mm; 3.6 mm
    Max. Aperture F1.6
    Field of View 2.8 mm: H: 113.3°; V: 62.1°; D: 134.3°
    3.6 mm: H: 90.1°; V: 47.8°; D: 109.3°
    Iris Control Fixed
    Close Focus Distance 2.8 mm: 0.8 m (2.62 ft)
    3.6 mm: 1.3 m (4.27 ft)
    DORI Distance
    Lens Detect Observe Recognize Identify
    2.8 mm 59.8 m
    ( 196.19 ft)    		 23.9 m
    ( 78.41 ft)    		 12.0 m
    ( 39.37 ft)    		 6.0 m

    ( 19.69 ft)
    3.6 mm 77 m
    ( 252.62 ft)    		 30.8 m
    ( 101.05 ft)    		 15.4 m
    ( 50.52 ft)    		 7.7 m

    ( 25.26 ft)
    *DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool.
    Video
    Video Frame Rate CVI:
    PAL: 5M@25 fps; 5M@12.5 fps; 4M@25 fps; 1080p@25 fps
    NTSC: 5M@25 fps; 5M@20 fps; 5M@10 fps; 4M@30 fps; 1080p@30 fps
    AHD:
    PAL: 4M@25 fps
    NTSC: 4M@30 fps
    TVI:
    PAL: 5M 16:9@20 fps
    NTSC: 5M 16:9@20 fps
    CVBS:
    PAL: 960H
    NTSC: 960H
    Resolution 5M (2880 × 1620); 4M (2560 × 1440); 1080p (1920 × 1080); 960H (960 × 576/960 × 480); TVI 5M 16:9 (2960 × 1665)
    Day/Night Auto(ICR)/Color/B/W
    BLC BLC; HLC; WDR
    WDR DWDR
    White Balance Auto;Area white balance
    Gain Control Auto
    Noise Reduction 3D NR
    Motion Detection Yes
    Illumination Mode Smart IR&WL; WL Mode; IR Mode
    Mirror Yes
    Privacy Masking Off/On (8 areas, rectangle)
    Pick-up Distance 8 m (26.25 ft)
    Certification
    Certifications CE-LVD: EN 62368-1;
    CE-EMC: EN 55032; EN 55035;
    Audio
    Built-in Mic Yes
    Camera Audio CVI; TVI
    Port
    Video Output Video output choices of CVI/TVI/AHD/CVBS by one BNC port (DIP Switch)
    Power
    Power Supply 12 VDC (±30%)
    Power Consumption Max 4.3 W (12 VDC, WLED on)
    Environment
    Operating Temperature –40 °C to +60 °C (–40 °F to +140 °F)
    Operating Humidity <95% (RH), non-condensing
    Storage Temperature –40 °C to +60 °C (–40 °F to +140 °F)
    Storage Humidity <95% (RH), non-condensing
    Protection IP67
    Anti-corrosion Level Basic Protection
    Structure
    Casing Material Plastic
    Product Dimensions 161.6 mm × 70.0 mm × 69.7 mm (6.36″ × 2.76″ × 2.74″) (L × W × H)
    Net Weight 0.20 kg (0.44 lb)
    Gross Weight 0.27 kg (0.60 lb)
    Installation Wall mount; ceiling mount; vertical pole mount
